Industrial & Drainage

Centrifugal Mud Pump & Self Priming Mud Pump

Dirty water with sand, silt and small stones destroys ordinary pumps. Delite's mud pumps are built non-clogging and self-priming for exactly that job.

  • 75 m³/hrMaximum capacity
  • 48 mMaximum head
  • 25 mmSolid size handled
  • 5 mSuction head

The Delite mud pump is a self-priming centrifugal pump with a non-clogging hydraulic design and a closed-grain cast iron base. It primes itself quickly and automatically, and passes solids up to 25 mm. Material options run from cast iron and carbon steel through SS 304/304L and SS 316/316L to bronze, Alloy-20, CD4MCU and Hastelloy B and C — so the same pump family can handle muddy site water or corrosive industrial slurries.

Centrifugal & Self Priming Mud Pump specifications

Mud pump operating data
CapacityUp to 75 m³/hr
HeadUp to 48 m
Suction headUp to 5 m
Discharge size40 mm to 80 mm
Solid sizeUp to 25 mm
TemperatureUp to 110 °C
SpeedUp to 3500 rpm
PressureUp to 4.8 kg/cm²
Voltage180 – 240 V single phase · 380 – 440 V three phase
MaterialsC.I.–C.S., SS 304/304L, SS 316/316L, bronze, Alloy-20, CD4MCU, Hastelloy B & C

Key features

  • Non-clogging design
  • Quick, automatic self-priming
  • Closed-grain CI cast base
  • Wide choice of corrosion-resistant alloys
  • Single or three phase drive

Applications

  • Construction site water
  • Mining and quarry dewatering
  • Sewage and drainage systems
  • Slurry and sludge transfer
  • Industrial dewatering
FAQ

Frequently asked questions

What is the difference between a mud pump and a dewatering pump?

Delite's mud pump is a surface-mounted self-priming pump that sucks dirty water up to 5 m. A submersible dewatering pump is lowered into the water itself.

What size of solids can the mud pump handle?

Up to 25 mm.

Do you supply mud pumps in Ahmedabad?

Yes — Delite manufactures mud pumps at its Bapunagar, Ahmedabad works.

Get a quote for Centrifugal & Self Priming Mud Pump

Tell us the water source, bore or well size, total head, required discharge and power supply. The Delite Pumps team in Ahmedabad will suggest a model and send a price.
