Centrifugal Mud Pump & Self Priming Mud Pump
Dirty water with sand, silt and small stones destroys ordinary pumps. Delite's mud pumps are built non-clogging and self-priming for exactly that job.



- 75 m³/hrMaximum capacity
- 48 mMaximum head
- 25 mmSolid size handled
- 5 mSuction head
The Delite mud pump is a self-priming centrifugal pump with a non-clogging hydraulic design and a closed-grain cast iron base. It primes itself quickly and automatically, and passes solids up to 25 mm. Material options run from cast iron and carbon steel through SS 304/304L and SS 316/316L to bronze, Alloy-20, CD4MCU and Hastelloy B and C — so the same pump family can handle muddy site water or corrosive industrial slurries.
Centrifugal & Self Priming Mud Pump specifications
| Capacity | Up to 75 m³/hr |
|---|---|
| Head | Up to 48 m |
| Suction head | Up to 5 m |
| Discharge size | 40 mm to 80 mm |
| Solid size | Up to 25 mm |
| Temperature | Up to 110 °C |
| Speed | Up to 3500 rpm |
| Pressure | Up to 4.8 kg/cm² |
| Voltage | 180 – 240 V single phase · 380 – 440 V three phase |
| Materials | C.I.–C.S., SS 304/304L, SS 316/316L, bronze, Alloy-20, CD4MCU, Hastelloy B & C |
Key features
- Non-clogging design
- Quick, automatic self-priming
- Closed-grain CI cast base
- Wide choice of corrosion-resistant alloys
- Single or three phase drive
Applications
- Construction site water
- Mining and quarry dewatering
- Sewage and drainage systems
- Slurry and sludge transfer
- Industrial dewatering
Related pumps

Submersible Dewatering Pump
DSDP series cast-iron dewatering and drainage pumps for construction, mining, tunnels and flood relief.
View details →
Sewage Submersible Pump
Cast-iron non-clog sewage pumps with IP68 4/6-pole motors and winding temperature and moisture sensors.
View details →
Submersible Pumps for Mining & Construction
Mine dewatering & site drainage
Read guide →
Centrifugal Monoblock Pump
Single and three-phase monoblocks for irrigation, cooling towers, clear-water industry and buildings.
View details →More in Industrial & Drainage
Frequently asked questions
What is the difference between a mud pump and a dewatering pump?
Delite's mud pump is a surface-mounted self-priming pump that sucks dirty water up to 5 m. A submersible dewatering pump is lowered into the water itself.
What size of solids can the mud pump handle?
Up to 25 mm.
Do you supply mud pumps in Ahmedabad?
Yes — Delite manufactures mud pumps at its Bapunagar, Ahmedabad works.
Get a quote for Centrifugal & Self Priming Mud Pump
Tell us the water source, bore or well size, total head, required discharge and power supply. The Delite Pumps team in Ahmedabad will suggest a model and send a price.
